Product Details:
|
| Commodity: | Free Sample One Inch Custom Size Aerosol Bag On Valve Aerosol Cans | Size: | One Inch |
|---|---|---|---|
| Application: | Cosmetics, Medical,Perfume , Body Spray , Cosmetic , Sunscreen , Deodorant,BBQ | Material: | Stainless Steel |
Designed for the food and beverage industry, this food-grade male bag on valve ensures hygienic dispensing of liquid creamers, sauces, and edible oils. Constructed from FDA-approved polymers, it resists corrosion and supports easy cleaning for allergen-free production. The wide-diameter nozzle prevents clogging, while the leak-proof design maintains product freshness. Ideal for dairy and beverage manufacturers, this BOV system integrates seamlessly with filling machines, reducing waste and ensuring portion control.
FDA-approved food-grade materials for safe consumption.
Wide-diameter nozzle prevents clogs in viscous products.
Leak-proof design preserves product freshness.
Compatible with dairy, sauces, and liquid condiments.
Easy disassembly for thorough cleaning.
Specific application scenario:
Used in coffee creamer production lines for precise, hygienic filling into single-serve containers.
Specifications:
BOV consists of a valve on which a flexible multilayer film bag, containing the product to be dispensed, is affixed or welded. The propellant, liquid gas or compressed gas (Nitrogen, air), is contained between the bag and can and squeezes the bag to release the product through the valve when the spray button is pressed.
|
Model |
Max Capacity |
Length and Height |
for aerosol can size |
|
JC-100-P250 |
300ml |
185*100 |
59*210 |
|
250ml |
53*210 |
||
|
JC-100-P200 |
220ml |
145*100 |
53*180 |
|
190ml |
50*180 |
||
|
JC-100-P150-1 |
150ml |
125*90 |
50*150/155 |
|
125ml |
45*150/155 |
||
|
JC-100-P100 |
120ml |
100*90 |
50*125 |
|
100ml |
45*125 |
||
|
JC-100-P80 |
80ml |
100*80 |
40*120/130 |
|
JC-100-P65 |
65ml |
90*80 |
40*110/035*110 |
|
JC-100-P50 |
50ml |
90*65 |
35*110 |
FAQ:
Q: Is it dishwasher-safe?
A: Yes, withstands temperatures up to 85°C.
Q: Can it handle carbonated beverages?
A: Designed for non-carbonated liquids only.
Q: Are replacement nozzles available?
A: Yes, sold as part of maintenance kits.
Q: Does it support hot-fill processes?
A: Rated for fills up to 60°C.
Q: Is it BPA-free?
A: Yes, compliant with global food safety standards.
